AFB0948HH image
Favorite
AFB0948HH image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 92X92X25.4MM 48V WIRE
PDF
/
Buying Options
Total Price: USD $14.44
Unit Price: USD $14.443163
≥1 USD $14.443163
≥10 USD $13.625625
≥100 USD $12.854367
≥500 USD $12.126764
≥1000 USD $11.440334
Inventory: 1174
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Mount Flanges
Weight 0.218lb 98.88g
Material - Frame Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Published 2011
Series AFB
Size / Dimension Square - 92mm Lx92mm H
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 48VDC
Power Rating 3.84W
Current Rating (Amps) 0.080A
Max Power Dissipation 3.84W
Reach Compliance Code unknown
Current Rating 80mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 57.9 CFM (1.62m3/min)
Noise 38.0 dB(A)
Voltage Range 28V~56VDC
Static Pressure 0.221 in H2O (55.0 Pa)

Dimensions

Height 92mm

Compliance

RoHS Status ROHS3 Compliant
