AFB0924H
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X25.4MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $11.87
Unit Price: USD $11.8712
≥1 USD $11.8712
≥10 USD $11.32912
≥100 USD $10.250592
≥500 USD $9.4413
≥1000 USD $8.470185
≥3000 USD $7.822769
Inventory: 526
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 92mm
Technical
Static Pressure 0.177 in H2O (44.1 Pa)
Voltage Range 14V~27.6VDC
Noise 34.0 dB(A)
Air Flow 51.2 CFM (1.43m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2850 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 100mA
Depth 92mm
Max Power Dissipation 2.4W
Current Rating (Amps) 0.100A
Voltage - Rated DC 24V
Power Rating 2.4W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 92mm Lx92mm H
Series AFB
Physical
Material - Frame Plastic
Weight 0.218lb 98.88g
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
