AFB0912UHE-A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Axial Ball Bearing 12V 7V to 13.2V 160.22CFM 63dB (92 X 92 X 38mm)
PDF
/
Inventory: 4886
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Length 92mm
Height 92mm
Technical
Static Pressure 1.002 in H2O (249.6 Pa)
Voltage Range 7V~13.2VDC
Noise 63.0 dB(A)
Air Flow 160.2 CFM (4.49m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 6000 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Depth 92mm
Current Rating (Amps) 2.50A
Power Rating 30W
Voltage - Rated 12VDC
Power (Watts) 30W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 92mm Lx92mm H
Series AFB
Published 2014
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic
Package / Case Axial
