AFB0912M-PM11
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X25.4MM 12VDC WIRE
PDF
/
Inventory: 4547
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP55, Water Resistant
RoHS Status RoHS Compliant
Dimensions
Width 25.40mm
Technical
Static Pressure 0.133 in H2O (33.1 Pa)
Voltage Range 5V~13.8VDC
Noise 31.5 dB(A)
Air Flow 49.5 CFM (1.39m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2300 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 120mA
Ingress Protection IP55 - Dust Protected, Water Resistant
Max Power Dissipation 1.44W
Current Rating (Amps) 0.120A
Voltage - Rated 12VDC
Power (Watts) 1.44W
Min Operating Temperature 14°C
Max Operating Temperature 158°C
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension Square - 92mm Lx92mm H
Series AFB
Published 2005
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.265lb 120.2g
Package / Case Axial
