AFB0912HHF-EP

Delta Electronics
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 92X32MM 12VDC WIRE
PDF
/
Inventory: 6090
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case Axial
Weight 0.353lb 160.12g
Material - Frame Plastic

Technical

Operating Temperature 14~140°F -10°C~60°C
Series AFB
Size / Dimension Square - 92mm Lx92mm H
Feature GR-487
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Current Rating (Amps) 0.200A
Max Power Dissipation 2.4W
Ingress Protection IP56 - Dust Protected, Water Resistant
Reach Compliance Code unknown
Current Rating 200mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 3000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 60.0 CFM (1.68m3/min)
Noise 38.0 dB(A)
Voltage Range 7V~15VDC
Static Pressure 0.209 in H2O (52.1 Pa)

Compliance

RoHS Status RoHS Compliant
Ratings IP56, Water Resistant
