AFB0912HH image
Favorite
AFB0912HH image
Favorite
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description AFB Series 3200 RPM 92 x 92 x 25.4 mm 57.92 CFM 12 VDC 2-Wire Ball Bearing Fan
PDF
/
Buying Options
Total Price: USD $8.59
Unit Price: USD $8.5888
≥1 USD $8.5888
≥10 USD $8.20072
≥100 USD $7.419456
≥500 USD $6.875
Inventory: 2529
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 25.4mm
Height 92mm

Technical

Rated Power 3W
Thermal Support Device Type DC FAN
Static Pressure 0.221 in H2O (55.0 Pa)
Voltage Range 7V~13.8VDC
Noise 38.0 dB(A)
Air Flow 57.9 CFM (1.62m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3200 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 250mA
Depth 92mm
Max Power Dissipation 3W
Current Rating (Amps) 0.250A
Voltage - Rated DC 12V
Power Rating 3W
Additional Feature APPROVALS: UL; VDE
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Size / Dimension Square - 92mm Lx92mm H
Series AFB
Published 2005

Physical

Material - Frame Plastic
Weight 0.218lb 98.88g
Package / Case Axial
Mount Flanges

Supply Chain

Factory Lead Time 19 Weeks
