AFB0912H-TA50

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 92X25.4MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $19.31
Unit Price: USD $19.307474
≥1 USD $19.307474
≥10 USD $18.214592
≥100 USD $17.183581
≥500 USD $16.210924
≥1000 USD $15.293325
Inventory: 1264
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Package / Case Axial
Weight 0.265lb 120.2g
Material - Frame Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Published 2005
Series AFB
Size / Dimension Square - 92mm Lx92mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 1.92W
Current Rating (Amps) 0.210A
Max Power Dissipation 2.52W
Ingress Protection IP55 - Dust Protected, Water Resistant
Current Rating 210mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 2800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 59.9 CFM (1.68m3/min)
Noise 37.0 dB(A)
Voltage Range 5V~13.8VDC
Static Pressure 0.191 in H2O (47.6 Pa)

Dimensions

Height 92mm

Compliance

RoHS Status ROHS3 Compliant
Ratings IP55, Water Resistant
