AFB0912EHE-AF00
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
92X92X38MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 5688
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.54lb 244.94g
Material - Frame Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2005
Series AFB
Size / Dimension Square - 92mm Lx92mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Voltage - Rated 12VDC
Power Rating 16.8W
Max Power Dissipation 16.8W
Depth 92mm
Reach Compliance Code unknown
Current Rating 1.4A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 4800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 127.3 CFM (3.56m3/min)
Noise 56.0 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.635 in H2O (158.2 Pa)
Dimensions
Height 92mm
Compliance
RoHS Status ROHS3 Compliant
