AFB0824LB image
Favorite
AFB0824LB image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Ball Bearing 24V 0.05A 1.2W 2400RPM 24.72CFM 27.5dB Flange Mount
PDF
/
Buying Options
Total Price: USD $13
Unit Price: USD $12.995047
≥1 USD $12.995047
≥10 USD $12.259481
≥100 USD $11.565548
≥500 USD $10.910889
≥1000 USD $10.293292
Inventory: 6499
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 15.00mm
Length 80mm
Height 80mm

Technical

Static Pressure 0.087 in H2O (21.7 Pa)
Voltage Range 14V~27.6VDC
Noise 27.5dB(A)
Air Flow 24.7 CFM (0.692m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2400 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.050A
Power Rating 1.2W
Voltage - Rated 24VDC
Power (Watts) 1.2W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 80mm Lx80mm H
Series AFB
Published 2012
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Blade Plastic
Material - Frame Plastic
Weight 0.128lb 58.06g
Housing Material Plastic

Supply Chain

Factory Lead Time 19 Weeks
