AFB0824HHB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 80X80X15 MM 24V WIRE
PDF
/
Buying Options
Total Price: USD $13.18
Unit Price: USD $13.1824
≥1 USD $13.1824
≥10 USD $12.58048
≥100 USD $11.38192
≥500 USD $10.48344
≥1000 USD $9.405106
≥3000 USD $8.686251
Inventory: 453
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 80mm
Technical
Static Pressure 0.159 in H2O (39.6 Pa)
Voltage Range 14V~27.6VDC
Noise 37.0 dB(A)
Air Flow 35.7 CFM (1.00m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3400 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 100mA
Reach Compliance Code unknown
Max Power Dissipation 2.4W
Current Rating (Amps) 0.100A
Power Rating 2.4W
Voltage - Rated 24VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension Square - 80mm Lx80mm H
Series AFB
Published 2014
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.128lb 58.06g
Supply Chain
Factory Lead Time 19 Weeks
