AFB0824HB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
80X80X15MM 24V DC FAN
PDF
/
Buying Options
Total Price: USD $13.18
Unit Price: USD $13.1824
≥1 USD $13.1824
≥10 USD $12.58048
≥100 USD $11.38192
≥500 USD $10.48344
≥1000 USD $9.405106
≥3000 USD $8.686251
Inventory: 193
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 15.00mm
Length 80mm
Height 80mm
Technical
Static Pressure 0.138 in H2O (34.3 Pa)
Voltage Range 14V~27.6VDC
Noise 34.0 dB(A)
Air Flow 33.6 CFM (0.941m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3100 RPM
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.080A
Power Rating 1.92W
Voltage - Rated 24VDC
Power (Watts) 1.92W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 80mm Lx80mm H
Series AFB
Published 2014
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.128lb 58.06g
Housing Material Plastic
Supply Chain
Factory Lead Time 19 Weeks
