AFB0812VHD-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
80X80X20MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Buying Options
Total Price: USD $14.56
Unit Price: USD $14.564
≥1 USD $14.564
≥10 USD $13.90488
≥100 USD $12.580832
≥500 USD $11.587664
≥1000 USD $10.395854
≥3000 USD $9.601258
Inventory: 610
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.161lb 73.03g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series AFB
Size / Dimension Square - 80mm Lx80mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 3 Wire Leads
Power (Watts) 5.04W
Voltage - Rated 12VDC
Power Rating 5.04W
Current Rating (Amps) 0.420A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 5400 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 63.5 CFM (1.78m3/min)
Noise 47.5 dB(A)
Voltage Range 5V~12.6VDC
Static Pressure 0.394 in H2O (98.1 Pa)
Dimensions
Height 80mm
Length 80mm
Width 20.00mm
Compliance
RoHS Status ROHS3 Compliant
