AFB0812SHD
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
AFB Series 4000 RPM 80 x 80 x 20 mm 48.2 CFM 12 VDC 2-Wire Ball Bearing Fan
PDF
/
Inventory: 10012
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Thermal Support Device Type DC FAN
Static Pressure 0.245 in H2O (61.0 Pa)
Voltage Range 7V~13.8VDC
Noise 41.0 dB(A)
Air Flow 48.2 CFM (1.35m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4000 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 220mA
Depth 20mm
Max Power Dissipation 2.64W
Current Rating (Amps) 0.220A
Voltage - Rated DC 12V
Power Rating 2.64W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension Square - 80mm Lx80mm H
Series AFB
Published 2003
Physical
Material - Frame Plastic
Weight 0.163lb 73.94g
Package / Case Axial
Mount Flanges
