AFB0812SH
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Axial Ball Bearing 12V 7V to 13.8V 46.62CFM 40dB (80 X 80 X 25.4mm)
PDF
/
Buying Options
Total Price: USD $13.18
Unit Price: USD $13.1824
≥1 USD $13.1824
≥10 USD $12.58048
≥100 USD $11.38192
≥500 USD $10.48344
≥1000 USD $9.405114
≥3000 USD $8.686251
Inventory: 186
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 25.4mm
Height 80mm
Technical
Thermal Support Device Type DC FAN
Static Pressure 0.267 in H2O (66.5 Pa)
Voltage Range 7V~13VDC
Noise 40.0 dB(A)
Air Flow 46.6 CFM (1.30m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4000 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 340mA
Depth 80mm
Max Power Dissipation 4.08W
Current Rating (Amps) 0.340A
Power Rating 4.08W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 80mm Lx80mm H
Series AFB
Published 2002
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.176lb 79.83g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
