AFB0812LD-A

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 80X80X20MM 12V WIRE
PDF
/
Buying Options
Total Price: USD $9.8
Unit Price: USD $9.8032
≥1 USD $9.8032
≥10 USD $9.35528
≥100 USD $8.464192
≥500 USD $7.842912
Inventory: 362
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 80mm

Technical

Static Pressure 0.129 in H2O (32.1 Pa)
Voltage Range 5V~13.8VDC
Noise 30.5 dB(A)
Air Flow 33.5 CFM (0.938m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3000 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 120mA
Reach Compliance Code unknown
Max Power Dissipation 1.44W
Current Rating (Amps) 0.120A
Power Rating 1.44W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension Square - 80mm Lx80mm H
Series AFB
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.161lb 73.03g

Supply Chain

Factory Lead Time 19 Weeks
