AFB0812HH
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
AFB Series 3250 RPM 80 x 80 x 25.4 mm 37.43 CFM 12 VDC 3 Wire Ball Bearing Fan
PDF
/
Buying Options
Total Price: USD $8.89
Unit Price: USD $8.88725
≥1 USD $8.88725
≥10 USD $7.2922
≥100 USD $7.0642
≥500 USD $6.8362
≥1000 USD $6.6082
Inventory: 29
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Package / Case Axial
Housing Material Plastic
Weight 0.176lb 79.83g
Material - Frame Plastic
Material - Blade Plastic
Technical
Published 2004
Series AFB
Size / Dimension Square - 80mm Lx80mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 2.4W
Voltage - Rated 12VDC
Power Rating 2.4W
Voltage - Rated DC 12V
Current Rating (Amps) 0.200A
Max Power Dissipation 2.4W
Depth 80mm
Current Rating 200mA
Approval Agency CE, CSA, UL, VDE
Cable Length 310mm
RPM 3250 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 37.4 CFM (1.05m3/min)
Noise 34.0 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.181 in H2O (45.1 Pa)
Dimensions
Height 80mm
Length 80mm
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
