AFB0812H image
Favorite
AFB0812H image
Favorite
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description AFB Series 3000 RPM 80 x 80 x 25.4 mm 35.31 CFM 12 VDC Ball Bearing Fan
PDF
/
Buying Options
Total Price: USD $9.27
Unit Price: USD $9.2664
≥1 USD $9.2664
≥10 USD $8.84312
≥100 USD $8.001312
≥500 USD $7.414
Inventory: 479
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Mount Flanges
Package / Case Axial
Weight 0.176lb 79.83g
Material - Frame Plastic

Technical

Published 2014
Series AFB
Size / Dimension Square - 80mm Lx80mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power Rating 1.92W
Voltage - Rated DC 12V
Current Rating (Amps) 0.160A
Max Power Dissipation 1.92W
Depth 80mm
Current Rating 160mA
Approval Agency CE, CSA, UL, VDE
RPM 3000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 35.3 CFM (0.988m3/min)
Noise 31.0 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.159 in H2O (39.6 Pa)
Thermal Support Device Type DC FAN

Dimensions

Height 80mm
Width 25.4mm

Compliance

RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
