AFB0805L image
Favorite
AFB0805L image
Favorite
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 80X25.4MM 5VDC WIRE
PDF
/
Buying Options
Total Price: USD $13.18
Unit Price: USD $13.1824
≥1 USD $13.1824
≥10 USD $12.58048
≥100 USD $11.38192
≥500 USD $10.48344
≥1000 USD $9.405114
≥3000 USD $8.686251
Inventory: 823
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 25.4mm
Height 80mm

Technical

Thermal Support Device Type DC FAN
Static Pressure 0.102 in H2O (25.5 Pa)
Voltage Range 4.5V~5.5VDC
Noise 25.0 dB(A)
Air Flow 27.9 CFM (0.781m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2400 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 240mA
Depth 80mm
Max Power Dissipation 1.2W
Current Rating (Amps) 0.240A
Power Rating 1.2W
Voltage - Rated 5VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 80mm Lx80mm H
Series AFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.176lb 79.83g
Package / Case Axial
Mount Flanges

Supply Chain

Factory Lead Time 19 Weeks
