AFB0724MB image
Favorite
AFB0724MB image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Ball Bearing 24V 0.09A 2.16W 3300RPM 28.18CFM 28.18dB Flange Mount
PDF
/
Inventory: 7580
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Housing Material Plastic
Weight 0.104lb 47.17g
Material - Frame Plastic
Material - Blade Plastic

Technical

Series AFB
Size / Dimension Square - 70mm Lx70mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Power (Watts) 2.16W
Voltage - Rated 24VDC
Power Rating 1.68W
Current Rating (Amps) 0.090A
Approval Agency CE, CSA, UR, VDE
RPM 3300 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 28.2 CFM (0.790m3/min)
Noise 31.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.123 in H2O (30.6 Pa)

Dimensions

Height 70mm
Length 70mm
Width 15.00mm

Compliance

RoHS Status ROHS3 Compliant
