AFB0712LB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 12V 0.08A 0.96W 2800RPM 23.38CFM 23.38dB Flange Mount
PDF
/
Buying Options
Total Price: USD $13.18
Unit Price: USD $13.1824
≥1 USD $13.1824
≥10 USD $12.58048
≥100 USD $11.38192
≥500 USD $10.48344
≥1000 USD $9.405114
≥3000 USD $8.686251
Inventory: 298
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.104lb 47.17g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2014
Series AFB
Size / Dimension Square - 70mm Lx70mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Power (Watts) 960mW
Voltage - Rated 12VDC
Power Rating 960mW
Current Rating (Amps) 0.080A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 2800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 23.4 CFM (0.655m3/min)
Noise 26.5 dB(A)
Voltage Range 4V~13.8VDC
Static Pressure 0.089 in H2O (22.2 Pa)
Dimensions
Height 70mm
Length 70mm
Width 15.00mm
Compliance
RoHS Status ROHS3 Compliant
