AFB0624VHB

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Ball Bearing 24V 0.11A 2.64W 5000RPM 19.42CFM 37dB Flange Mount
PDF
/
Buying Options
Total Price: USD $4.66
Unit Price: USD $4.655706
≥1 USD $4.655706
≥10 USD $4.395384
Inventory: 6
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Housing Material Plastic
Weight 0.098lb 44.45g
Material - Frame Plastic
Material - Blade Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Published 2014
Series AFB
Size / Dimension Square - 60mm Lx60mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Power (Watts) 2.64W
Voltage - Rated 24VDC
Power Rating 2.64W
Current Rating (Amps) 0.110A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 5000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 19.4 CFM (0.543m3/min)
Noise 37.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.240 in H2O (59.8 Pa)

Dimensions

Height 60mm
Length 60mm
Width 15.00mm

Compliance

RoHS Status ROHS3 Compliant
