AFB0624MB-R00
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
60X60X15MM 24V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 7575
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Weight 0.098lb 44.45g
Material - Frame Plastic
Material - Blade Plastic
Technical
Published 2014
Series AFB
Size / Dimension Square - 60mm Lx60mm H
Feature Locked Rotor Sensor
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Power (Watts) 1.44W
Voltage - Rated 24VDC
Current Rating (Amps) 0.060A
Max Power Dissipation 1.44W
Current Rating 60mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 13.4 CFM (0.375m3/min)
Noise 29.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.119 in H2O (29.6 Pa)
Dimensions
Width 15.00mm
Compliance
RoHS Status RoHS Compliant
