AFB0624MB
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
AFB Series 3500 RPM 60 x 60 x 15 mm 13.45 CFM 24 VDC Ball Bearing Fan
PDF
/
Buying Options
Total Price: USD $12.71
Unit Price: USD $12.7072
≥1 USD $12.7072
≥10 USD $12.13168
≥100 USD $10.976768
≥500 USD $10.110144
≥1000 USD $9.070204
≥3000 USD $8.376931
Inventory: 484
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.098lb 44.45g
Material - Frame Plastic
Technical
Published 2011
Series AFB
Size / Dimension Square - 60mm Lx60mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 24VDC
Power Rating 1.44W
Current Rating (Amps) 0.060A
Max Power Dissipation 1.44W
Depth 60mm
Reach Compliance Code unknown
Current Rating 60mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 3500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 13.4 CFM (0.375m3/min)
Noise 29.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.119 in H2O (29.6 Pa)
Dimensions
Height 60mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
