AFB0624M-A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 60X25.4MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $10.34
Unit Price: USD $10.34
≥1 USD $10.34
≥10 USD $9.86656
≥100 USD $8.927072
≥500 USD $8.272
Inventory: 1143
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 60mm
Technical
Static Pressure 0.155 in H2O (38.6 Pa)
Voltage Range 14V~27.6VDC
Noise 31.0 dB(A)
Air Flow 19.8 CFM (0.554m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3600 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 70mA
Reach Compliance Code unknown
Max Power Dissipation 1.68W
Current Rating (Amps) 0.070A
Power Rating 1.68W
Voltage - Rated 24VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.176lb 79.83g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
