AFB0624HD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
60X60X20MM 24V DC FAN
PDF
/
Buying Options
Total Price: USD $12.36
Unit Price: USD $12.3552
≥1 USD $12.3552
≥10 USD $11.7964
≥100 USD $10.67264
≥500 USD $9.830128
Inventory: 248
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.137lb 62.14g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series AFB
Size / Dimension Square - 60mm Lx60mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Power (Watts) 1.2W
Voltage - Rated 24VDC
Power Rating 1.2W
Current Rating (Amps) 0.050A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 4000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 16.6 CFM (0.465m3/min)
Noise 28.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.189 in H2O (47.1 Pa)
Dimensions
Height 60mm
Length 60mm
Width 20.00mm
Compliance
RoHS Status ROHS3 Compliant
