AFB0624HB
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Axial Ball Bearing 24V 14V to 27.6V 15.36CFM 32dB (60 X 60 X 15mm)
PDF
/
Buying Options
Total Price: USD $12.71
Unit Price: USD $12.7072
≥1 USD $12.7072
≥10 USD $12.13168
≥100 USD $10.976768
≥500 USD $10.110144
≥1000 USD $9.070204
≥3000 USD $8.376931
Inventory: 1112
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Package / Case Axial
Weight 0.098lb 44.45g
Material - Frame Plastic
Technical
Published 2006
Series AFB
Size / Dimension Square - 60mm Lx60mm H
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power Rating 1.92W
Voltage - Rated DC 24V
Current Rating (Amps) 0.080A
Max Power Dissipation 1.92W
Depth 60mm
Reach Compliance Code unknown
Current Rating 80mA
Approval Agency CE, CSA, UL, VDE
RPM 4000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 15.4 CFM (0.431m3/min)
Noise 32.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.155 in H2O (38.6 Pa)
Dimensions
Height 60mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
