AFB0624EH-A

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Ball Bearing 24V 0.24A 5.76W 6800RPM 38.35CFM 46.5dB Flange Mount
PDF
/
Buying Options
Total Price: USD $14.7
Unit Price: USD $14.7048
≥1 USD $14.7048
≥10 USD $14.036
≥100 USD $12.699104
≥500 USD $11.696608
≥1000 USD $10.493507
≥3000 USD $9.691466
Inventory: 1142
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 60mm

Technical

Static Pressure 0.544 in H2O (135.5 Pa)
Voltage Range 14V~27.6VDC
Noise 46.5 dB(A)
Air Flow 38.3 CFM (1.07m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 6800 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 240mA
Reach Compliance Code unknown
Depth 60mm
Max Power Dissipation 5.76W
Current Rating (Amps) 0.240A
Power Rating 5.76W
Voltage - Rated 24VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.176lb 79.83g
Package / Case Axial
Mount Flanges

Supply Chain

Factory Lead Time 19 Weeks
