AFB0612SH-A

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Axial Ball Bearing 12V 4V to 13.8V 34.15CFM 44.5dB (60 X 60 X 25.4mm)
PDF
/
Inventory: 7054
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 60mm

Technical

Static Pressure 0.422 in H2O (105.1 Pa)
Voltage Range 4V~13.8VDC
Noise 44.5 dB(A)
Air Flow 34.1 CFM (0.955m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 6000 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 270mA
Reach Compliance Code unknown
Depth 60mm
Max Power Dissipation 3.24W
Current Rating (Amps) 0.270A
Power Rating 3.24W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.176lb 79.83g
Package / Case Axial
Mount Flanges

Supply Chain

Factory Lead Time 19 Weeks
