Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 60X60X13MM 12V DC FAN
PDF
/
Inventory: 3743
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 13.00mm
Length 60mm
Height 60mm

Technical

Static Pressure 0.119 in H2O (29.6 Pa)
Voltage Range 7V~13.8VDC
Noise 28.0 dB(A)
Air Flow 18.2 CFM (0.510m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3600 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.110A
Power Rating 1.32W
Voltage - Rated 12VDC
Power (Watts) 1.32W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2012
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Blade Plastic
Material - Frame Plastic
Weight 0.074lb 33.56g
Housing Material Plastic

Supply Chain

Factory Lead Time 19 Weeks
