AFB0612M-A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Axial Ball Bearing 12V 4V to 13.8V 19.78CFM 31dB (60 X 60 X 25.4mm)
PDF
/
Inventory: 8424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 25.40mm
Length 60mm
Height 60mm
Technical
Static Pressure 0.155 in H2O (38.6 Pa)
Voltage Range 4V~13.8VDC
Noise 31.0 dB(A)
Air Flow 19.8 CFM (0.554m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3600 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Depth 60mm
Current Rating (Amps) 0.130A
Power Rating 1.56W
Voltage - Rated 12VDC
Power (Watts) 1.56W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2014
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.176lb 80.00g
Housing Material Plastic
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
