AFB0612HHD
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 60X20MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $13.84
Unit Price: USD $13.8424
≥1 USD $13.8424
≥10 USD $13.21496
≥100 USD $11.956032
≥500 USD $11.01232
≥1000 USD $9.879566
≥3000 USD $9.12443
Inventory: 787
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 60mm
Technical
Static Pressure 0.229 in H2O (57.0 Pa)
Voltage Range 7V~13.8VDC
Noise 31.0 dB(A)
Air Flow 18.4 CFM (0.515m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4400 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 150mA
Depth 60mm
Max Power Dissipation 1.8W
Current Rating (Amps) 0.150A
Voltage - Rated DC 12V
Power Rating 1.8W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Physical
Material - Frame Plastic
Weight 0.137lb 62.14g
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
Alternative Model
