AFB0612HD-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
60X60X20MM 12V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 6539
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 60mm
Technical
Static Pressure 0.189 in H2O (47.1 Pa)
Voltage Range 7V~13.8VDC
Noise 28.0 dB(A)
Air Flow 16.6 CFM (0.465m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4000 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 110mA
Reach Compliance Code unknown
Max Power Dissipation 1.32W
Current Rating (Amps) 0.110A
Power Rating 1.32W
Voltage - Rated 12VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Locked Rotor Sensor
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.137lb 62.14g
Supply Chain
Factory Lead Time 19 Weeks
