AFB0612H-EP

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 60X25.4MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $25.21
Unit Price: USD $25.208085
≥1 USD $25.208085
≥10 USD $23.781213
≥100 USD $22.435107
≥500 USD $21.165194
≥1000 USD $19.967163
Inventory: 1156
Minimum: 1
-
+

Technical Details

Compliance

Ratings IP56, Water Resistant
RoHS Status ROHS3 Compliant

Dimensions

Height 60mm

Technical

Static Pressure 0.211 in H2O (52.6 Pa)
Voltage Range 5V~13.8VDC
Noise 34.0 dB(A)
Air Flow 22.6 CFM (0.633m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4250 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 140mA
Reach Compliance Code unknown
Ingress Protection IP56 - Dust Protected, Water Resistant
Max Power Dissipation 1.68W
Current Rating (Amps) 0.140A
Power Rating 1.68W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature GR-487
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2010
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.176lb 79.83g
Package / Case Axial

Supply Chain

Factory Lead Time 19 Weeks
