AFB0612EH-AR00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 60X25.4MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $40.68
Unit Price: USD $40.681519
≥1 USD $40.681519
Inventory: 3727
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 60mm
Technical
Static Pressure 0.544 in H2O (135.5 Pa)
Voltage Range 4V~13.8VDC
Noise 46.5 dB(A)
Air Flow 38.3 CFM (1.07m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 6800 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 380mA
Reach Compliance Code unknown
Max Power Dissipation 4.56W
Current Rating (Amps) 0.380A
Power Rating 4.56W
Voltage - Rated 12VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Sensor
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.176lb 79.83g
Supply Chain
Factory Lead Time 19 Weeks
