AFB0612EH-ABRR0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 60X25.4MM 12VDC WIRE
PDF
/
Inventory: 7150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.176lb 79.83g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2006
Series AFB
Size / Dimension Square - 60mm Lx60mm H
Feature Locked Rotor Sensor
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Power (Watts) 4.56W
Voltage - Rated 12VDC
Current Rating (Amps) 0.380A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 6800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 38.3 CFM (1.07m3/min)
Noise 46.5 dB(A)
Voltage Range 4V~13.8VDC
Static Pressure 0.544 in H2O (135.5 Pa)
Dimensions
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
