AFB0612EH-A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 12V 0.38A 4.56W 6800RPM 38.35CFM 46.5dB Flange Mount
PDF
/
Buying Options
Total Price: USD $14.7
Unit Price: USD $14.7048
≥1 USD $14.7048
≥10 USD $14.036
≥100 USD $12.699104
≥500 USD $11.696608
≥1000 USD $10.493507
≥3000 USD $9.691466
Inventory: 207
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 60mm
Technical
Static Pressure 0.544 in H2O (135.5 Pa)
Voltage Range 4V~13.8VDC
Noise 46.5 dB(A)
Air Flow 38.3 CFM (1.07m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 6800 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 380mA
Reach Compliance Code unknown
Depth 60mm
Max Power Dissipation 4.56W
Current Rating (Amps) 0.380A
Power Rating 4.56W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2011
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.176lb 79.83g
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
