AFB0605HHB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
60X60X15MM 5V DC FAN
PDF
/
Inventory: 9426
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 60mm
Technical
Static Pressure 0.195 in H2O (48.6 Pa)
Voltage Range 4V~6VDC
Noise 35.0 dB(A)
Air Flow 17.3 CFM (0.484m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4500 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.400A
Power Rating 2W
Voltage - Rated 5VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 60mm Lx60mm H
Series AFB
Published 2012
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.098lb 44.45g
Supply Chain
Factory Lead Time 19 Weeks
