AFB0512HHB
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 50X50X15MM 12V WIRE
PDF
/
Buying Options
Total Price: USD $7.81
Unit Price: USD $7.8128
≥1 USD $7.8128
≥10 USD $6.4106
≥100 USD $6.21015
≥500 USD $6.01065
≥1000 USD $5.8102
Inventory: 10
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 50mm
Technical
Static Pressure 0.315 in H2O (78.5 Pa)
Voltage Range 7V~13.8VDC
Noise 36.0 dB(A)
Air Flow 16.2 CFM (0.454m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 6400 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 130mA
Reach Compliance Code unknown
Depth 50mm
Max Power Dissipation 1.56W
Current Rating (Amps) 0.130A
Power Rating 1.56W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension Square - 50mm Lx50mm H
Series AFB
Published 2005
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.071lb 32.21g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
