AFB04512MA

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 45X10MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $10.14
Unit Price: USD $10.1376
≥1 USD $10.1376
≥10 USD $9.47848
≥100 USD $8.596544
≥500 USD $7.935136
≥1000 USD $6.943288
≥3000 USD $6.502461
Inventory: 404
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Mount Flanges
Package / Case Axial
Housing Material Plastic
Weight 0.034lb 15.42g
Material - Frame Plastic
Material - Blade Plastic

Technical

Published 2011
Series AFB
Size / Dimension Square - 45mm Lx45mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 1.32W
Voltage - Rated 12VDC
Power Rating 1.32W
Voltage - Rated DC 12V
Current Rating (Amps) 0.110A
Max Power Dissipation 1.32W
Depth 45mm
Current Rating 110mA
Approval Agency CE, CSA, UL, VDE
RPM 5000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 9.9 CFM (0.277m3/min)
Noise 30.0 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.127 in H2O (31.6 Pa)

Dimensions

Height 45mm
Length 45mm
Width 10.00mm

Compliance

RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
