AFB0312HA-A

Delta Electronics
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 30X10MM 12VDC WIRE
PDF
/
Inventory: 8825
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 30mm

Technical

Static Pressure 0.100 in H2O (24.9 Pa)
Voltage Range 9.5V~13.8VDC
Noise 25.0 dB(A)
Air Flow 3.5 CFM (0.098m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 9000 RPM
Life (Hours) 30000 hours
Lifetime @ Temp 30000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 90mA
Reach Compliance Code unknown
Depth 30mm
Max Power Dissipation 1.08W
Current Rating (Amps) 0.090A
Power Rating 1.08W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Size / Dimension Square - 30mm Lx30mm H
Series AFB
Published 2007
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.023lb 10.43g
Package / Case Axial
Mount Flanges

Supply Chain

Factory Lead Time 18 Weeks
