AFB02512HHA
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 25X10MM 12VDC WIRE
PDF
/
Inventory: 5964
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Axial
Weight 0.023lb 10.43g
Material - Frame Plastic
Technical
Published 2005
Series AFB
Size / Dimension Square - 25mm Lx25mm H
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power Rating 960mW
Voltage - Rated DC 12V
Current Rating (Amps) 0.080A
Max Power Dissipation 960mW
Depth 25mm
Reach Compliance Code unknown
Current Rating 80mA
Approval Agency CE, CSA, UL, VDE
RPM 13000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 2.4 CFM (0.067m3/min)
Noise 28.0 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.300 in H2O (74.7 Pa)
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
