1-NPT/603-1469
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN - 603-1469/WM2312TR/WM2001
PDF
/
Inventory: 8898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Weight 0.564lb 255.83g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2010
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Position Rectangular Connector
Voltage - Rated 12VDC
Current Rating (Amps) 0.600A
Max Power Dissipation 7.2W
Ingress Protection IP55 - Dust Protected, Water Resistant
Current Rating 600mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3200 RPM
Bearing Type Ball
Fan Type Tubeaxial, Case Fan
Air Flow 130.0 CFM (3.64m3/min)
Noise 48.0 dB(A)
Voltage Range 4V~13.2VDC
Static Pressure 0.420 in H2O (104.6 Pa)
Compliance
RoHS Status ROHS3 Compliant
Ratings IP55, Water Resistant
