1-NPT/603-1325
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN - 603-1325/WM2312TR/WM2001
PDF
/
Buying Options
Total Price: USD $30.82
Unit Price: USD $30.8176
≥1 USD $30.8176
≥10 USD $28.66512
≥100 USD $25.798784
≥500 USD $23.648944
≥1000 USD $22.215688
≥3000 USD $19.349158
Inventory: 90
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 38.00mm
Technical
Static Pressure 1.082 in H2O (269.5 Pa)
Voltage Range 6V~12.8VDC
Noise 62.0 dB(A)
Air Flow 241.0 CFM (6.75m3/min)
Fan Type Tubeaxial, Case Fan
Bearing Type Ball
RPM 5200 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 2.45A
Max Power Dissipation 29.4W
Current Rating (Amps) 2.45A
Voltage - Rated 12VDC
Power (Watts) 29.4W
Min Operating Temperature 14°C
Max Operating Temperature 158°C
Termination 3 Position Rectangular Connector
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Speed Sensor (Tach)
Size / Dimension Square - 120mm Lx120mm H
Series AFB
Published 2007
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.728lb 330.22g
