1-NPT/603-1078
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN - 603-1078/WM2312TR/WM2001
PDF
/
Buying Options
Total Price: USD $19.21
Unit Price: USD $19.2104
≥1 USD $19.2104
≥10 USD $18.34008
≥100 USD $16.59328
≥500 USD $15.283136
≥1000 USD $13.711192
≥3000 USD $12.663235
Inventory: 56
Minimum: 1
-
+
Technical Details
Physical
Weight 0.565lb 256.28g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2004
Series AFB
Size / Dimension Square - 120mm Lx120mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Position Rectangular Connector
Max Operating Temperature 140°C
Min Operating Temperature 14°C
Power (Watts) 7.2W
Voltage - Rated 12VDC
Current Rating (Amps) 0.600A
Max Power Dissipation 7.2W
Current Rating 600mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3200 RPM
Bearing Type Ball
Fan Type Tubeaxial, Case Fan
Air Flow 129.9 CFM (3.64m3/min)
Noise 48.0 dB(A)
Voltage Range 4V~13.2VDC
Static Pressure 0.420 in H2O (104.6 Pa)
Dimensions
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
