CFM-A225V-131-445-20
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X25MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $13.2
Unit Price: USD $13.2
≥1 USD $13.2
≥10 USD $12.60248
≥100 USD $11.85228
≥500 USD $11.402274
≥1000 USD $10.50207
≥3000 USD $9.826925
Inventory: 271
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Weight 0.357lb 161.93g
Material - Frame Polybutylene Terephthalate (PBT)
Material - Blade Polybutylene Terephthalate (PBT)
Technical
Operating Temperature 14~158°F -10°C~70°C
Series CFM-120V
Size / Dimension Square - 120mm Lx120mm H
Feature Auto Restart, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 3 Wire Leads
Power (Watts) 4.84W
Voltage - Rated 12VDC
Current Rating (Amps) 0.403A
Approval Agency CE, cURus, TUV
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3100 RPM
Bearing Type omniCOOL? Magnetic Sleeve
Fan Type Tubeaxial
Air Flow 108.2 CFM (3.03m3/min)
Noise 44.5 dB(A)
Voltage Range 4.5V~13.2VDC
Static Pressure 0.280 in H2O (69.7 Pa)
Dimensions
Width 25.00mm
Compliance
RoHS Status RoHS Compliant
