CFM-8025-13-11
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC AXIAL FAN, 80 MM SQUARE, 25 M
PDF
/
Inventory: 3311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Package / Case Axial
Material - Frame Polybutylene Terephthalate (PBT)
Material - Blade Polybutylene Terephthalate (PBT)
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2016
Series CFM-80
Size / Dimension Square - 80mm Lx80mm H
Feature Locked Rotor Sensor
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination 3 Wire Leads
Max Operating Temperature 158°C
Min Operating Temperature 14°C
Power (Watts) 5.16W
Voltage - Rated 12VDC
Current Rating (Amps) 0.330A
Max Power Dissipation 5.16W
Current Rating 330mA
Approval Agency CE, CUR, TUV, UL
RPM 5100 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 69.2 CFM (1.94m3/min)
Noise 47.0 dB(A)
Voltage Range 6V~13.8VDC
Static Pressure 0.424 in H2O (105.6 Pa)
Dimensions
Width 25.40mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
