CFM-8010-13-10
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC AXIAL FAN, 80 MM SQUARE, 10 M
PDF
/
Buying Options
Total Price: USD $9.27
Unit Price: USD $9.267007
≥1 USD $9.267007
≥10 USD $8.742459
≥100 USD $8.247608
≥500 USD $7.780767
≥1000 USD $7.340336
Inventory: 1145
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Material - Frame Polybutylene Terephthalate (PBT)
Material - Blade Polybutylene Terephthalate (PBT)
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2016
Series CFM-80
Size / Dimension Square - 80mm Lx80mm H
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Max Operating Temperature 158°C
Min Operating Temperature 14°C
Power (Watts) 2.88W
Voltage - Rated 12VDC
Current Rating (Amps) 0.160A
Max Power Dissipation 2.88W
Current Rating 160mA
Approval Agency CE, CUR, TUV, UL
RPM 3300 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 33.6 CFM (0.941m3/min)
Noise 38.2 dB(A)
Voltage Range 6V~13.8VDC
Static Pressure 0.110 in H2O (27.4 Pa)
Dimensions
Width 10.60mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
