CFM-7010-13-20
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC AXIAL FAN, 70 MM SQUARE, 10 M
PDF
/
Inventory: 5128
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 10.60mm
Technical
Static Pressure 0.164 in H2O (40.9 Pa)
Voltage Range 6V~13.8VDC
Noise 40.6 dB(A)
Air Flow 31.1 CFM (0.871m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4400 RPM
Approval Agency CE, CUR, TUV, UL
Current Rating 220mA
Max Power Dissipation 3.24W
Current Rating (Amps) 0.220A
Voltage - Rated 12VDC
Power (Watts) 3.24W
Min Operating Temperature 14°C
Max Operating Temperature 158°C
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Speed Sensor (Tach)
Size / Dimension Square - 70mm Lx70mm H
Series CFM-70
Published 2017
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Polybutylene Terephthalate (PBT)
Material - Frame Polybutylene Terephthalate (PBT)
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
