CFM-6020V-237-280
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 60X20MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $5.23
Unit Price: USD $5.2272
≥1 USD $5.2272
Inventory: 471
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Weight 0.112lb 50.8g
Material - Frame Polybutylene Terephthalate (PBT)
Material - Blade Polybutylene Terephthalate (PBT)
Technical
Operating Temperature 14~158°F -10°C~70°C
Series CFM-60V
Size / Dimension Square - 60mm Lx60mm H
Feature Auto Restart
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Power (Watts) 1.35W
Voltage - Rated 24VDC
Current Rating (Amps) 0.042A
Approval Agency CE, cURus, TUV
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 4200 RPM
Bearing Type omniCOOL? Magnetic Sleeve
Fan Type Tubeaxial
Air Flow 19.0 CFM (0.532m3/min)
Noise 28.0 dB(A)
Voltage Range 8V~27.6VDC
Static Pressure 0.160 in H2O (39.8 Pa)
Dimensions
Width 20.00mm
Compliance
RoHS Status RoHS Compliant
