CBM-979533B-168
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 97X33MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $20.43
Unit Price: USD $20.4336
≥1 USD $20.4336
≥10 USD $18.66304
≥100 USD $17.95442
≥500 USD $16.77324
Inventory: 195
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 33.00mm
Technical
Static Pressure 5.220 in H2O (1300.3 Pa)
Voltage Range 6V~12.6VDC
Noise 69.9 dB(A)
Air Flow 54.7 CFM (1.53m3/min)
Fan Type Blower
Bearing Type Ball
RPM 6800 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, cURus, TUV
Current Rating (Amps) 3.85A
Voltage - Rated 12VDC
Power (Watts) 48.3W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Auto Restart
Size / Dimension Rectangular/Rounded - 97mm Lx95mm H
Series CBM-97B
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Polybutylene Terephthalate (PBT)
Material - Frame Polybutylene Terephthalate (PBT)
Weight 0.406lb 184.16g
Supply Chain
Factory Lead Time 22 Weeks
